DJI Mavic 3 Multispectral

DJI Mavic 3 Multispectral

การสำรวจทางอากาศที่มีประสิทธิภาพ ต้องมองเห็นสิ่งที่มองไม่เห็นด้วยตาเปล่า ดังนั้น DJI Mavic 3 Multispectral จึงมีระบบภาพสองแบบ โดยรวมกล้องถ่ายภาพ RGB เข้ากับกล้องถ่ายภาพมัลติสเปกตรัม เพื่อสแกนและวิเคราะห์การเจริญเติบโตของพืชได้อย่างชัดเจน การจัดการผลผลิตทางการเกษตร ต้องอาศัยความแม่นยำและข้อมูล ซึ่ง Mavic 3M มอบทั้งสองสิ่งนี้

·       Multispectral Camera

·       RGB Camera

·       Precise positioning

·       Efficient aerial surveying

·       Compact and portable

·       Safe and stable

ข้อมูลสินค้า

Aircraft

1.      Net Weight (with propellers and RTK module) 951 g

2.      Max Takeoff Weight 1,050 g

3.      Dimensions (Folded/Unfolded) Folded (without propellers): 223×96.3×122.2 mm (Length×Width×Height), Unfolded (without propellers): 347.5×283×139.6 mm (Length×Width×Height)

4.      Diagonal Length Diagonal: 380.1 mm

5.      Max Ascent Speed 6 m/s (Normal Mode), 8 m/s (Sport Mode)

6.      Max Descent Speed 6 m/s (Normal Mode),6 m/s (Sport Mode)

7.      Max Flight Speed (at sea level, no wind) 15 m/s (Normal Mode) Flying forward: 21 m/s, flying sideways: 20 m/s, flying backwards: 19 m/s (Sport mode)

8.      Max Wind Speed Resistance 12 m/s

9.      Max Take-off Altitude Above Sea Level 6000 m (without a payload)

10.   Max Flight Time (without wind) 43 minutes

11.   Max Hover Time (without wind) 37 minutes

12.   Max Flight Distance 32 km

13.   Max Pitch Angle 30° (Normal Mode), 35° (Sport Mode)

14.   Max Angular Velocity 200°/s

15.   GNSS GPS + Galileo + BeiDou + GLONASS (GLONASS is supported only when RTK module is enabled)

16.   Hovering Accuracy Range Vertical: ±0.1 m (Vision Positioning enabled); ±0.5 m (GNSS Positioning enabled); ±0.1 m (D-RTK enabled), Horizontal: ±0.3 m (Vision Positioning enabled); ±0.5 m (HD Positioning enabled); ±0.1 m (RTK enabled)

17.   Operating Temperature -10° to 40° C (14° to 104° F)

18.   Motor Model Number 2008

19.   Propeller Model Number 9453F Enterprise Edition

20.   Light Sensor Built-in module

RGB Camera

1.      Image Sensor 4/3 CMOS Effective Pixels: 20 MP

2.      Lens FOV: 84° Equivalent focal length: 24 mm Aperture: f/2.8 to f/11 Focus: 1 m to ∞

3.      ISO Range 100-6400

4.      Shutter speed Electronic shutter: 8-1/8000 s, Mechanical shutter: 8-1/2000 s

5.      Max Image Size 5280×3956

6.      Photo Shooting Mode Single shot: 20 MP, Timelapse: 20 MP, JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s, JPEG + RAW: 3/5/7/10/15/20/30/60 s, Panorama: 20 MP (original material)

7.      Video Resolution H.264: 4K: 3840×2160@30fps, FHD: 1920×1080@30fps

8.      Max Video Bitrate 4K: 130Mbps FHD: 70Mbps

9.      Supported File System exFAT

10.   Image Format JPEG/DNG (RAW)

11.   Video Format MP4 (MPEG-4 AVC/H.264)

Multispectral Camera

1.      Image Sensor 1/2.8-inch CMOS, effective pixels: 5 MP

2.      Lens FOV: 73.91° (61.2° x 48.10°), Equivalent focal length: 25 mm, Aperture: f/2.0, Focus: Fixed Focus

3.      Multispectral Camera Band Green (G): 560 ± 16 nm; Red (R): 650 ± 16 nm; Red Edge (RE): 730 ± 16 nm; Near infrared (NIR): 860 ± 26 nm;

4.      Gain Range 1x-32x

5.      Shutter Speed Electronic Shutter: 1/30~1/12800 s

6.      Max Image Size 2592×1944

7.      Image Format TIFF

8.      Video Format MP4 (MPEG-4 AVC/H.264)

9.      Photo Shooting Mode Single shot: 5 MP, Timelapse: 5 MP, TIFF: 2/3/5/7/10/15/20/30/60 s

10.   Video Resolution H.264, FHD: 1920 x 1080@30fps, Video content: NDVI/GNDVI/NDRE

11.   Max Video Bitrate Stream: 60 Mbps

Gimbal

1.      Stabilization System 3-axis mechanical gimbal (tilt, roll, pan)

2.      Mechanical Range Tilt: -135° to 45°, Roll: -45° to 45°, Pan: -27° to 27°

3.      Controllable Range Tilt: -90° to 35°, Pan: Uncontrollable

4.      Max Control Speed (tilt) 100°/s

5.      Angular Vibration Range ±0.007°

Sensing System

1.      Sensing System Type Omnidirectional binocular vision system, with an infrared sensor at the bottom of the aircraft

2.      Forward

a.      Distance Measuring Range: 0.5 m to 20 m

b.      Detection Range: 0.5 m to 200 m

c.      Effective Obstacle Avoidance Speed: Flight Speed ≤15 m/s

d.      FOV: Horizontal 90°, vertical 103°

3.      Backward

a.      Distance Measuring Range: 0.5 m to 16 m

b.      Effective Obstacle Avoidance Speed: Flight speed ≤12 m/s

c.      FOV: Horizontal 90°, vertical 103°

4.      Lateral

a.      Distance Measuring Range: 0.5 m to 25 m

b.      Effective Obstacle Avoidance Speed: Flight speed ≤15 m/s

c.      FOV: Horizontal 90°, vertical 85°

5.      Upward

a.      Distance Measuring Range: 0.2 m to 10 m

b.      Effective Obstacle Avoidance Speed: Flight Speed ≤6 m/s

c.      FOV: Front and rear 100°, left and right 90°

6.      Downward

a.      Distance Measuring Range: 0.3 m to 18 m

b.      Effective Obstacle Avoidance Speed: Flight speed ≤6 m/s

c.      FOV: Front and rear 130°, left and right 160°

7.      Operating Environment Front, Rear, Left, Right, above: Surfaces with clear patterns and adequate lighting (> 15 lux, environments with normal indoor fluorescent light exposure) Below: Surfaces with diffuse reflection material and a reflectivity of >20% (such as walls, trees, people, etc.); Adequate lighting (>15 lux, environments with normal indoor fluorescent light exposure)

Video Transmission

1.      Video Transmission System DJI O3 Image Transmission Industry Edition

2.      Live View Quality Remote Controller: 1080p/30fps

3.      Operating Band

a.      2.400-2.4835 GHz

b.      5.725-5.850 GHz

4.      Max Effective Signal Distance (Unobstructed, No interference)

a.      FCC: 15 km

b.      CE: 8 km

c.      SRRC: 8 km

d.      MIC: 8 km

5.      Max Transmission Distance (Obstructed)

a.      Strong Interference (urban landscapes, residential areas, etc.): 1.5-3 km (FCC/CE/SRRC/MIC)

b.      Medium Interference (suburban landscapes, city parks, etc.): 3-9 km (FCC), 3-6 km (CE/SRRC/MIC)

c.      Weak Interference (remote fields, open farmland, etc.): 9-15 km (FCC), 6-8 km (CE/SRRC/MIC)

6.      Max Download Speed 15 MB/s (with DJI RC Pro Industry Edition)

7.      Latency (depending on environment and mobile device) Approximately 200 milliseconds

8.      Antennas 4 antennas, 2 transmitting and 4 receiving

9.      Transmitter Power (EIRP)

a.      2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)

b.      5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE) Other

10.   Other Supports the DJI Cellular module

DJI RC Pro Enterprise Edition

1.      Image Transmission System DJI O3 Image Transmission Industry Edition

2.      Max Effective Signal Distance (Unobstructed, No interference) FCC: 15 km CE: 8 km SRRC: 8 km MIC: 8 km

3.      Operating Band of Image Transmission

a.      2.400-2.4835 GHz

b.      5.725-5.850 GHz

4.      Antennas 4 antennas, 2 transmitting and 4 receiving

5.      Operating Band of Image Transmission and Transmitter Power (EIRP)

a.      2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC)

b.      5.8 GHz: <33 dBm (FCC); <14 dBm (CE); <23 dBm (SRRC)

6.      Wi-Fi Protocol

a.      802.11 a/b/g/n/ac/ax

b.      Support 2×2 MIMO Wi-Fi

7.      Wi-Fi Operating Band

a.      2.400-2.4835 GHz

b.      5.150-5.250 GHz

c.      5.725-5.850 GHz

8.      Wi-Fi Operating Band and Transmitter Power (EIRP)

a.      2.4 GHz: <26 dBm (FCC); <20 dBm (CE/SRRC/MIC)

b.      5.1 GHz: <26 dBm (FCC); <23 dBm (CE/SRRC/MIC)

c.      5.8 GHz: <26 dBm (FCC/SRRC); <14 dBm (CE)

9.      Bluetooth Protocol Bluetooth 5.1

10.   Bluetooth Operating Band 2.400-2.4835 GHz

11.   Bluetooth Transmitter Power (EIRP) <10 dBm

12.   Screen Resolution 1920×1080

13.   Screen Size 5.5 inches

14.   Screen Frame Rate 60 fps

15.   Screen Brightness 1,000 nits

16.   Touch-Screen 10-point multi-touch

17.   Battery Lithium-ion battery (5000 mAh, 7.2 V)

18.   Charging Type 100W Battery Charging Hub or USB charger with 12V or 15V specifications is recommended

19.   Rated Power 12 Watts

20.   Storage Capacity Internal Memory (ROM): 64 GB

21.   Supports microSD card usage to increase storage capacity

22.   Charging Time

a.      Approx. 1.5 hours (measured when only using the 100W Battery Charging Hub to charge the remote control, or when using a 15V USB charger)

b.      Approximately 2 hours (measured using a 12V USB charger)

c.      Approximately 2 hours and 50 minutes (measured using the 100W Battery Charging Hub to charge the aircraft and remote control at the same time)

23.   Operating Time Approx. 3 hours

24.   Video Output Port Mini-HDMI Port

25.   Operating Temperature -10° to 40° C (14° to 104°F)

26.   Storage Temperature Range

a.      <1 month: -30° to 60° C (-22° to 140° F)

b.      One to three months: -30° to 45° C (-22° to 113° F)

c.      Three to six months: -30° to 35° C (-22° to 95° F)

d.      More than six months: -30° to 25° C (-22° to 77° F)

27.   Charging Temperature5° to 40° C (41° to 104° F)

28.   Supported DJI Aircraft DJI Mavic 3M

29.   GNSS GPS + Galileo + GLONASS

30.   Dimensions

a.      Antenna is folded and no control sticks are installed: 183.27×137.41×47.6 mm (Length×Width×Height)

b.      Antenna unfolded and control sticks are installed:183.27×203.35×59.84 mm (Length×Width×Height)

31.   Weight Approx. 680 g

32.   Model Number RM510B

Battery

1.      Capacity 5000 mAh

2.      Standard Voltage 15.4 V

3.      Max Charging Voltage 17.6 V

4.      Battery Type LiPo 4S

5.      Chemical System Lithium Cobalt

6.      Energy 77 watt-hours

7.      Weight 335.5 g

8.      Charging Temperature 5° to 40° C (41° to 104° F)

Battery Charger

1.      Input 100V to 240V (AC), 50Hz to 60Hz, 2.5A

2.      Output Power 100 Watts

3.      Output Maximum output power of 100 Watts (total) When both the ports are used, the maximum output power of one interface is 82 W, and the charger will dynamically allocate the output power of the two interfaces according to load power.

Charging Hub

1.      Input USB-C: 5V to 20V, 5.0A

2.      Output Battery Port: 12V to 17.6V, 8.0A

3.      Rated Power 100 Watts

4.      Charging Type 3 batteries on charging rotation

5.      Charging Temperature 5° to 40° C (41° to 104° F)

RTK Module

1.      Dimensions 50.2×40.2×66.2 mm (Length×Width×Height)

2.      Weight 24±2 g

3.      Interface USB-C

4.      Power Approximately 1.2 watts

5.      RTK Position Accuracy Fixed RTK: Horizontal: 1 cm + 1 ppm; Vertical: 1.5 cm + 1 ppm
